The battery charge discharge tester is a regenerative design lithium-ion cell tester with high test accuracy and good stability. Each channel can be independently programmed and controlled.
Model:
WA-BTS-A5V100ACertificate:
CE Certificate issued by TÜV, UL CertificateTest channels:
48CH/Cabinet (Customizable)Voltage range/CH:
0V~5V (Customizable)Voltage accuracy:
±0.05%FS (20~30℃)Current range/CH:
±100A (Customizable)Current accuracy:
±0.05%FS (20~30℃)Warranty:
One year warranty with lifetime supportProduct Detail
Lithium-ion Cell Tester
Regenerative Design Battery Charge Discharge Tester
Functional description:
The battery charge discharge tester is a computer-controlled energy feedback type lithium-ion cell tester that integrates the charge-discharge cycles test, learning test, cell performance test, battery capacity test, battery internal resistance test and battery deep discharge test, etc.
Regenerative Design Battery Charge Discharge Tester (Both voltage and current can be customized) |
||
Product model |
Voltage range / CH |
Current range / CH |
WA-BTS-A5V60A |
0V~5V |
±60A |
WA-BTS-A5V100A |
0V~5V |
±100A |
WA-BTS-A5V200A |
0V~5V |
±200A |
WA-BTS-A5V300A |
0V~5V |
±300A |
WA-BTS-A5V500A |
0V~5V |
±500A |
WA-BTS-A5V600A |
0V~5V |
±600A |
WA-BTS-A5V1000A |
0V~5V |
±1000A |
WA-BTS-A5V1200A |
0V~5V |
±1200A |
WA-BTS-A5V1500A |
0V~5V |
±1500A |
WA-BTS-A5V3000A |
0V~5V |
±3000A |
For more product models, please click "Battery Test Systems" to view or contact us. |
Applicable range:
The battery charge discharge tester can be applied to the high-power battery cells, energy storage battery cells and large capacity battery cells, etc.
Advantages:
1) Modular design, high integration, good stability and easy maintenance.
2) The discharge energy can be reused by other channels and then return to the power grid, which can save energy and promote the charge accuracy.
3) Efficiency of the battery charge discharge tester (2.5m output line): when more than half load, the peak value of charge efficiency is up to 70% and discharge efficiency up to 60%, which can reduce the energy consumption cost.
4) Miniaturization, long service life, the lithium-ion cell tester improves the production environment.
5) Wide-range voltage and current adjustment, the lithium-ion cell tester can be applied to various batteries.
6) Sophisticated charge-discharge protection functions, the battery charge discharge tester can reduce industrial accidents.
7) Single point control, each channel of the battery charge discharge tester is independently controlled, which has high production efficiency.
8) Ethernet communication.
9) Automatically reconnecting after power loss.
Test items:
1) Battery charge learning test: constant current, constant voltage, constant power, constant resistance, constant current converting to constant voltage, current step, current ramp, pulse, cycle and rest.
2) Test step: ≥9999 steps; cycle index: ≥9999 times; unlimited program storage.
Set the jump and end conditions according to the conventional variables (voltage, current, time, capacity, energy, power and temperature) and custom variables.
3) The lithium-ion cell tester test software adopts “menu-type programming” for real-time working condition file (EXCEL format) import. The working condition files can be obtained by artificial editing and working condition acquisition system.
4) Charge cut-off conditions: voltage, current, time and capacity and custom variable etc.
5) Voltage, current, temperature and capacity monitoring during cycling.
6) Protections: over-voltage, over-current, over-power, under-voltage, over-temperature, reversed polarity, output short-circuit, electric leakage, outrage protection etc.
7) Countermeasure system of AC electric system faults: when the input end of power grid has faults like short circuit and phase failure, the battery charge discharge tester shall run normally without influencing the battery on the output end.
8) Self-diagnosis: When the lithium-ion cell tester malfunctions, such as over-temperature and overload, the battery charge discharge tester can judge itself and promptly make alarms and take relevant protection actions.
9) Working condition simulation: the lithium-ion cell tester supports the standard working condition simulation of power battery and the data files can be converted into test files.
10) The battery charge discharge tester supports zero-voltage discharge.
Technical specifications
Product name |
Battery Test Systems |
|
Product model |
WA-BTS-A5V100A |
|
Number of channels |
48CH/Cabinet (Customizable) |
|
Parallel connection of channels |
Available |
Max. 3000A (in parallel) Note: make clear while ordering. |
Current/channel |
Range |
±100A |
Accuracy |
20~30℃: ±0.05% F.S. |
|
0~45℃: ±0.1% F.S. |
||
Resolution |
0.1mA |
|
Voltage/channel |
Range |
0V~5V |
Accuracy |
20~30℃: ±0.05% F.S. |
|
0~45℃: ±0.1% F.S. |
||
Resolution |
0.1mV |
|
Measuring accuracy of channel power |
≤0.2% F.S. |
|
Voltage response time |
<10ms (resistance load) |
The transition time for the output voltage to ramp from 10% to 90% of the set value (The rise time of voltage) Note: For higher demands, it can be customized. |
Current response time |
<10ms (battery load) |
The transition time for the output current to ramp from 10% to 90% of the set value (The rise time of current) Note: For higher demands, it can be customized. |
Switching time between charge and discharge |
<20ms |
|
Min. interval of data recording |
10ms |
|
External temperature measurement |
-40℃~120℃ |
|
Temperature accuracy |
±1℃ |
|
Functions |
Constant voltage, constant current, constant power, constant current converting to constant voltage, constant resistance, current ramp, voltage ramp and pulse etc. |
Note: Any steps can be programmed to operate in any combination of operating modes. |
Calibration |
Auto |
1) Provide 1-year free automatic calibration service. 2) Provide paid calibration service or purchase an automated calibration device for those exceed 1-year free automatic calibration service. |
Lengths of the output line and sampling line |
2.5m (Main channel output cable, data acquisition cable and sampling cable of the auxiliary channel.) |
Can be customized. |
Heat dissipation |
Forced cooling |
|
Power grid (Customizable) |
380VAC±15% / 50~60Hz Three-phase five-wire system |
The whole cabinet |
220VAC±10% / 50~60Hz |
A single chassis |
|
Ripple coefficient |
≤1% F.S. |
|
Harmonics of the current returning to the power grid |
≤5% |
|
Efficiency |
Charge: 0.70, from power grid to battery Discharge: 0.60, from battery to power grid |
While 2.5m output line configured |
Power factor |
>99% |
When ≥ 30% rated power |
Others |
Noise |
≤70dB |
IP rating |
IP20 |
|
Unexpected outage protection |
Available |
Unexpected power outage will suspend the current steps, which will be automatically resumed after power is restored. |
Automatic reconnection |
Available |
The battery cell cycler will suspend the current steps and continue to run when the computer resumes normal. |
Energy feedback |
Available |
The discharge energy fed back to the power grid. |
Minimum Simulation Time |
100ms |
|
Size(W*D*H) |
800*800*1768mm |
|
Weight |
800kg |
