The lithium ion battery vibration tester machine is used to simulate vibration during transport or use to perform vibration tests in standards such as UN38.3, IEC62133, UL 1642 and UL 2054, etc.
Model:
WA-ST-50-JVTNote 1:
Vibration Waveform: Sinusoidal waveformNote 2:
Peak Acceleration: 20gNote 3:
Vibration Frequency: 1~600Hz (Customizable)Note 4:
Vibration Direction: X-axis & Y-axis & Z-axisNote 5:
Vibration Table: W500*D500mm (Customizable)Product Detail
Vibration Test System
Lithium Ion Battery Vibration Tester Machine
Functional Description:
The lithium ion battery vibration tester machine is one of the professional battery testers for battery mechanical tests. It performs battery vibration tests by simulating the vibration environment of the battery during transport or use to confirm that its safety meets the requirements of the corresponding test standards, providing reliable testing and verification for battery design, manufacturing, safe transportation and safe use, etc.
Scope of Application:
The lithium ion battery vibration tester machine is used for battery vibration test in battery safety performance tests.
Features:
1) The lithium ion battery vibration tester machine can adjust the amplitude steplessly, supports logarithmic frequency sweep vibration, sweep frequency vibration and fixed frequency vibration modes, adapts to the requirements of different test standards, and has high flexibility.
2) The vibration test system can realize X, Y, and Z three-axis vibration on the same vibration test table. It is controlled by program, with precise frequency and no drift during long-term operation.
3) The lithium ion battery vibration tester machine has built-in vibration amplitude prediction program, four-point synchronous excitation, and the table vibrates evenly, stably and reliably.
4) The control system software of the vibration test system uses real-time communication connection with the vibration table to ensure that the test parameters are accurate.
5) The lithium ion battery vibration tester machine adds anti-interference circuit to solve the interference of strong electromagnetic field to the control circuit, and the table is free of magnetism and static electricity.
6) The control system of the lithium ion battery vibration tester machine adopts a high-sensitivity touch-screen color LCD display. The test parameter setting is intuitive and simple, and it can display the current execution program and the current vibration frequency in real time and draw frequency curves.
Technical Specifications of Vibration Test System
|
1. Product |
|
|
1.1 Product Name |
Lithium Ion Battery Vibration Tester Machine |
|
1.2 Product Model |
WA-ST-50-JVT |
|
1.3 Product Type |
Electromagnetic Vibration Machine for Battery Safety Testing |
|
2. Application |
|
|
2.1 Application |
The vibration test system is used to simulate the vibration environment of the battery during transportation or normal use to verify the safety performance of the battery. |
|
3. Dimensions & Weight |
|
|
3.1 Vibration Table Dimensions |
W500*D500mm (Customizable) |
|
3.2 Vibration Platform Dimensions |
W500*D500*H720mm |
|
3.3 Control Cabinet Dimensions |
W500*D350*H1080mm |
|
3.4 Weight |
About 245KG |
|
4. AC Input Power |
|
|
4.1 AC Input Power |
Single-phase 220VAC±10%, 50Hz±2.5Hz, 1.5kW (Customizable) |
|
5. Performance |
|
|
5.1 Vibration Waveform |
Sinusoidal waveform |
|
5.2 Vibration Frequency |
Range: 1~600Hz (Customizable) |
|
Resolution: 0.1Hz |
|
|
5.3 Peak Acceleration |
20g |
|
5.4 Time Range |
0~9999Hours/Minutes/Seconds |
|
5.5 Cycle Times |
0~9999 |
|
5.6 Max. Weight of Test Sample |
≤50KG (Customizable) |
|
5.7 Vibration Direction |
Three-axes (X-axis & Y-axis & Z-axis) |
|
5.8 Vibration Amplitude |
0~5mm |
|
5.9 Amplitude Modulation Method |
Electronic Amplitude Modulation |
|
5.10 Cooling Method |
Air Cooling |
|
6. Standard Compliance |
|
|
6.1 Standard Compliance |
1) UN38.3 - 38.3.4.3 Test T.3: Vibration 2) IEC62133 - 7.3.8.1 Mechanical tests (batteries) – Vibration 3) UL 1642 - 15 Vibration Test 4) UL 2054 - 17 Vibration Test 5) ECE R100 - Annex 8A: Vibration test 6) Etc. |
|
7. Controller |
|
|
7.1 Controller |
7-inch touch screen controller |
|
7.2 Vibration Test Mode |
1) Logarithmic frequency sweep vibration test: In logarithmic frequency sweep mode, the low frequency sweep speed is slow and the high frequency sweep speed is fast. The logarithmic frequency sweep is in units of 1 minute, and the sweep rate doubles in 1 minute. |
|
2) Fixed frequency vibration test: At a set frequency, which can be a resonant frequency, a specific frequency, or a dangerous frequency, a sinusoidal vibration test is performed at the specified frequency and time. |
|
|
3) Sweep frequency vibration test: Within the specified frequency range, the frequency is swept from low frequency to high frequency and then from high frequency to low frequency at a certain scanning rate according to the specified value until the specified number of cycles or time is reached. |
|
|
4) Frequency doubling vibration test: The frequency doubling sweep should be continuous and its frequency should change exponentially with time. The sweep rate, that is, the rate of change of the controllable variable frequency over time df/dt during the sweep, should be one frequency doubling per minute. The test time (acceleration time) for a frequency sweep from f1 → f2 → f1 is calculated using the formula: 6.644log10 (high frequency/low frequency), and the sweep rate meets the requirement of 1 frequency doubling /minute. |
|
|
5) Random vibration test: Random vibration is a non-deterministic vibration. When an object vibrates randomly, it is impossible for us to determine in advance the instantaneous value of the motion parameter of a certain monitoring point on the object at a certain moment in the future. |
|
|
6) Program vibration test: According to the test requirements, different test frequencies and times can be set, either single cycle or multi-cycle combination. |
|
|
8. Safety Protection |
|
|
8.1 Safety Protection |
Over-temperature, phase loss, short circuit, over-current and overload protection. |
Figure 1. Battery Vibration Tester Machine (Three-axis vibration test system)
